Specifications
Please reference the specification guide below to help you select the correct solution for your needs.
PART NUMBER | BH3130010-2 |
POWER SUPPLY | 110/230VAC, 31A max, Single Phase |
FUSE PROTECTION | 32A (FWC high speed) |
MAX OUTPUT POWER CHANNEL | 3400W @ 230VAC 3400W @ 208VAC 1500W @ 110VAC |
RECEPTION FREQUENCY | 916MHz |
OPERATING TEMPERATURE RANGE | -4 to 122°F |
DIMENSIONS | 8”x 5.7” x 3.3” |
PROTECTION CLASS | IP54 |
APPROVAL CERTIFICATION | UL & cUL E470263 |
