Manual Wall Switch

The new manual wall switches allow for simple on/off control of your outdoor heaters.
Manual Wall Switch

Manual Wall Switch

Price range: $99.00 through $229.00

Bromic’s Manual Wall Switches are the simple on/off solution for outdoor heating control. With indoor and covered outdoor single and double pole options, the 20 Amp, 120/277 volt manual wall switches can be placed where convenient access is needed.

Controls Manual Outdoor Wall Switch Product Brief Controls Indoor Manual Wall Switch Product Brief Download Full Catalog
SKU: N/A Category:
Talk to Sales

Product Resources

Specifications

MODEL BH3130071 BH3130072 BH3130081 BH3130082
DESCRIPTION Manual Single
20Amp Switch 120-
277V Indoor Kit		 Manual Dual
20Amp Switch 120-
277V Indoor Kit		 Manual Single
20Amp Switch 120-
277V Outdoor Kit		 Manual Dual
20Amp Switch 120-
277V Outdoor Kit
AMPERAGE 20 A 20 A 20 A 20 A
Dielectric Voltage Withstands 1500V for 1 min. Withstands 1500V for 1 min. Withstands 1500V for 1 min. Withstands 1500V for 1 min.
ENDURANCE 50,000 cycles minimum 50,000 cycles minimum 50,000 cycles minimum 50,000 cycles minimum
GROUNDING Self-Grounding Self-Grounding Self-Grounding Self-Grounding
TEMPERATURE RISE Maximum 30 degrees C rise Maximum 30 degrees C rise Maximum 30 degrees C rise Maximum 30 degrees C rise
VOLTAGE 120/277 VAC 120/277 VAC 120/277 VAC 120/277 VAC
OPERATING TEMPERATURE -40°C to 65°C -40°C to 65°C -40°C to 65°C -40°C to 65°C
SWITCH COLOR WHITE WHITE WHITE WHITE
WALL PLATE COLOR WHITE WHITE GREY GREY
WARRANTY 1 Year Parts
Downloads

Dimensions



Installation

Downloads

FAQs

Can I control an entire heater with a single switch?

These wall switches are rated at 20amps per switch and not all heaters can be controlled by one switch. It is up to a certified electrician to determine use case. For example, a 6000W Tungsten heater has two 3000W elements and will be able to have individual element control for power variability.

What products are compatible with wall switches?

All Tungsten and Platinum models in both gas and electric are compatible.

Are the wall switch kits surface mount or in-wall?

The indoor wall switch kit is in-wall and the outdoor wall switch kit is surface mounted.

What color is the switch and box?

The switch is a standard white and the switch box is a dark gray.

What size breaker and wire do I need for these switches?

This will be determined by a licensed electrician/installer in accordance with local code.
